Automotive PCBA Custom Circuit Board Printing Fabrication Car Radio Fm Electronics Printed Circuit Board

High frequency circuit boards
High frequency PCB with Rogers material
The increasing complexity of electronic components and switches continually requires faster signal flow rates, and thus higher transmission frequencies. Because of short pulse rise times in electronic components, it has also become necessary for high frequency (HF) technology to view conductor widths as an electronic component.

Depending on various parameters, HF signals are reflected on circuit board, meaning that the impedance (dynamic resistance) varies with respect to the sending component. To prevent such capacitive effects, all parameters must be exactly specified, and implemented with the highest level of process control.

Critical for the impedances in high frequency circuit boards are principally the conductor trace geometry, the layer buildup, and the dielectric constant (εr) of the materials used.

Product Description:

Company Introduction

FASTPCBA provide full turnkey contract included Custom design, PCB prototype, PCB, PCBA, PCB Assembly, testing, accessories and cables, plastic enclosure,and packaging.box building.
EMS include consumers electronic ,medicla, industrial,power control, automotive. Temperature & Humidity ,Internet & Communication Smart Home Security etc device .

Our Services & Strength

FASTPCBA is the best pcb manufacturing and pcb assembly factory globally, with ISO9001, ISO13485, 14000, and IATF16949 certificates simultaneously.

FASTPCBA keeps pace with the times, has imported advanced YAMAHA, MADATA, selective wave soldering, 3D AOI, X-RAY etc equiments, we can provide original package componets agent service, custom pcb manufacturing, precise pcb assembly, accurate pcb printing, save your cost and time at the same time.

All PCBA are double Check by Machines and QC work , Welcome to Visit our factory!

More PCBA Case

Our services specialize in prototyping & OEM and small-volume production, making your requirment complete on the one-stop destination of boards fabrication and assembly.

FASTPCBA Co., Ltd. is a professional PCB manufacturer in China, Shenzhen. With 20 years of development, FASPCBA turns into a first class manufacturer of PCB /PCBA. FASTPCBA is providing high quality bare PCB and PCB assembly service,including components sourcing, function test,conformal coating and complete assembly for clients all over the world, Our main market is Europe, north USA, Australia, South America, and Asia.

FASTPCBA has been selected as the “excellent partner of the year” by numerous well-known enterprises, and won many domestic and authorized certifications at home and abroad, such as Chinese high-tech project certification, ISO9001, ISO14001, ISO13485, IATF16949 quality management system standard and customized CE, UL, FCC and other product certifications according to the customer's requirements.

Millions of circuit boards are produced here every year, which provides superior service for automotive electronics, medical electronics, power communications, industrial automation, intelligent home and other industries around the world. We will continue to improve our quality and service; customer satisfaction and development of science and technology are our eternal motivation.

We have profuse experience in manufacturing PCB and PCBA. Fastpcba PCB daily capacity is 1200 square meters, we can deliver the Single sided, Double sided PCB sample within 24 hours, 4-8 layer PCB in 3-5 working days,for the batch quantity for double side PCB,The lead time is 3-5 working days, 4-8 layers is 5-8 days. The quick and fast lead time stably ensures our customer of quick research speed to occupying the market.

We have imported the advanced machinery from US,Japan,German and Israel to improve our production and technical ability.We have set a great example the PCB field of flying probe testing,buried and blind via and special controlled impedance.We have a highly developed R&D division which has helped our factory successfully produce mechanical micro via,high density impedance and HDI.
