PCB Manufacturing Electronic Component Fast SMT PCBA Prototype
Making Service
Our PCB PCBA Sevices:
1. PCB fabrication (Rigid PCB, Flexible PCB, Rigid-flex PCB).
2. Turnkey PCBA: PCB+components+SMT and through-hole
assembly+enclosure molding&housing
Our Advantage:
1. Free programming and free functional test, free package.
2. High quality: IPC-A-610E standard, E-test, X-ray, AOI test, QC,
100% funtional test.
3. Professional service: SMT and through hole assembly, over 20
years experience.
4. Certification: ISO9001, ISO14001, ISO13485, IATF16949.
PCB Manufacturing Capability:
* Accept Stardard: IPC III, Military, Automotive, Medcial, We offer
you expanded PCB capabilities: Rigid PCB, Flexible, Rigid-flex, HDI
board, High TG PCB
* Manufacture PCB board up to 56 layer, Raw material: Fr4, Rogers,
Arlon, Teflon, Taconic, Nelco, Isola, Ceramic, Metal core
* Support PCB surface process: HASL-LF, ENIG, Plating gold,
Immersion tin, Immersion silver, ENIPIG, OSP.
| Article | Description | Capability |
| Laminate Materials | FR4, high TG FR4, high frequency, alum, FPC |
| Board Cutting | Number of layers | 1-48 |
Min.thickness for inner layers
(Cu thickness are excluded) | 0.003”(0.07mm) |
| Board Thickness | Standard | (0.1-4mm±10%) |
| Min. | Single/Double:0.008±0.004” |
| 4layer:0.01±0.008” |
| 8layer:0.01±0.008” |
| Bow and twist | no more than 7/1000 |
| Copper Weight | Outer Cu weight | 0.5-4 0z |
| Inner Cu weight | 0.5-3 0z |
| Drilling | Min size | 0.0078”(0.2mm) |
| Drill deviation | ±0.002″(0.05mm) |
| PTH hole tolerance | ±0.002″(0.005mm) |
| NPTH hole tolerance | ±0.002″(0.005mm) |
| Solder Mask | Color | Green,white,black,red,blue… |
| Min solder mask clearanace | 0.003″(0.07mm) |
| Thickness | (0.012*0.017mm) |
| Silkscreen | Color | white,black,yellow,blue… |
| Min size | 0.006″(0.15mm) |
| Component Sourcing | Yes |
| Tolerance of PCB | ±5% |
| Max Size of Finish Board | 700*460mm |
| MOQ | NO MOQ (1pcs) |
| Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… |
| PCB Outline | Square,circle,irregular(with jigs) |
| Package | QFN,BGA,SSOP,PLCC,LGA |
| Sub-assembly | Plastic,metal,screen |
| Min Line/Space | 0.075/0.075mm |
Flexible Volume Assembly Alternatives:
* Prototype PCB Assembly
* Low-Volume, High Mix PCB Assembly
* High-Volume PCB Assembly
* Consigned & Partial PCB Assembly
* Full Turnkey PCB Assembly
* Cable & Wire Harness Assembly
* Box Build Assembly Services
| Feature | Capability |
| Quality Grade | Standard IPC 3 |
| Order Quantity | 1pc - 10,000+pcs |
| Build Time | 1 - 3 days, 1 - 3 weeks, or scheduled deliveries PCB Spec
Requirements |
| Max board size | 700x460 mm |
| Board Type | Rigid PCBs, Flexible PCBs, Rigid-flex PCB, Metal core PCBs, HDI
PCB, Gold-Plated PCB |
| Surface finish | HASL, ENIG, immersion gold, immersion silver, immersion tin, OSP… |
| Assembly Types | Surface mount
Thro-hole
Mixed technology (SMT & Thru-hole)
Single or double sided placement
Conformal coating
Shield cover assembly for EMI emission control |
| Solder Type | Lead-free - RoHS |
| Parts Procurement | full accordance with the customer's designated supplier.
Can also help customers reviwe and improve the supply chain |
| Function Test | 100% Functional test |
| PCBA Testing | X-ray,AOI Test,Functional test |
| PCB outline | Square,circle,irregular(with jigs) |
| Sub-assembly | Plastic,metal,screen |
Why Choose FASTPCBA?
With 20 years of development, FASPCBA turns into a first class
manufacturer of PCB and PCB Assembly,with production capability
35,000 square meters. We provide our customers with PCB solutions
and services worldwide.especially more than 80% printed circuit
board are exported to oversea market.
PCBA Testing With Multi-step Verification
Although we are fast on every process , we never ignore the
quality, our experienced QC team and highest advanced equipment can
make sure your prototypes good quality and best fully-functional.
Certifications:
FASTPCBA has been selected as the “excellent partner of the year”
by numerous well-known enterprises, and won many domestic and
authorized certifications at home and abroad, such as Chinese
high-tech project certification, ISO9001, ISO14001, ISO13485,
IATF16949 quality management system standard and customized CE, UL,
FCC and other product certifications according to the customer's
requirements.
Application:
Millions of circuit boards are produced here every year, which
provides superior service for automotive electronics, medical
electronics, power communications, industrial automation,
millitary, aviation & aerospace, intelligent home and other
industries around the world. We will continue to improve our
quality and service; customer satisfaction and development of
science and technology are our eternal motivation.
